BMW F06 650i COUPE Workshop Service Manual

$50.00$50.00
In stock
SKU:
Categories:Manual PDF
Shipping By Link Download
Shipping By Link Download
Secure Private Information
Secure Private Information
Guarantee Secure Payment
Guarantee Secure Payment

Support Contact:

Admin@autoepcsoft.org

BMW F06 650i COUPE Workshop Service Manual

Size: 248 MB
Language: English
Machine: Automotive
Machine Model: BMW F06 650i COUPE
Document: Workshop Service Manual
Pages: 4675 Pages

The Bookmarks of BMW F06 650i COUPE Workshop Service Manual:
Repair Instructions
 00 Maintenance and general note
   00 Maintenance
     Battery: Check battery. If necessary, recharging battery.
     BMW Quality Certification I
     BMW rapid inspection
     Body: Check for corrosion (except cavities)
     Brake lines and connections: visual inspection for leaks, damage, attachment and correct position
     CBS reset
     Check horn, headlight flashers and hazard warning flashers
     Check windscreen wash/wipe system
     Checking coolant level and concentration, correcting if necessary
     Checking instrument/inscription lighting, interior/luggage compartment/glove box lights and blower
     Checking lighting system
     Checking of road safety (test drive)
     Engine oil consumption measurement
     Pre-delivery check
     Seat belts: Check condition of seat belt strap, check function of automatic reel, seat belt locking reel, seat belt buckle, seat belt clip and, if necessary, seat belt clasp
     Service - air filter element
     Service - brake fluid
     Service - engine oil
     Service - front brakes
     Service - microfilter
     Service - rear brakes
     Service - spark plugs
     Service - vehicle check
     Service engine oil (US version only)
     Standard scope of service
     Steering components: Check for play, damage and, if nec., tightness
     Steering fluid fuel tank: Check oil level.
     Tyres: checking and if necessary correcting inflation pressure, checking condition, tread depth and pattern
     Underbody incl. all visible components: Check for damage, correct position, tightness, corrosion
     Vehicle care measures for inventory vehicles (new and used vehicles) as well as vehicles to be taken off the road that are in the hands of customers
     When driving on a race track
     Windscreen washer system: checking fluid level, topping up if necessary
     Wiring harness and connections: Check for damage, mounting and correct position
     Work instruction for removing the protective film
