DIECI L3500 L4700 F7000 Maintenance Manual AXH1157

Data Size: 11.26 MB
File Type: PDF
Language: English
Manufacturer: DIECI
Applicable Machine: Truck Mixer
Document: Maintenance Manual
Machine Model: DIECI
AB L 3500, AB L 3500 T, AB L 4700, AB L 4700 T, AB F 7000, AB F 7000 T
Engine: FPT NEF Stage IIIA/Tier 3 93 kW (125 HP)
Area: CE
Book Number: AXH1157
Publication Date: 07.2014
Page: 199 Pages

List Contents:

1 Info
1.1 General information
1.2 Identification of the vehicle
Table of Contents
Definitions
2 Introduction
2.1 Manual structure
2.2 Purpose and content
2.3 Preservation
2.4 Recipients
2.5 Hazard Classification
2.6 Machine general warnings
2.7 Equipment general warnings
2.8 Intended use
2.9 Contraindications for use
2.10 Declaration of first test
2.11 Liability
2.12 Manufacturer
2.13 Vehicle identification label
2.14 Certification and CE marking
2.15 Units of measurement and abbreviations used
3 Warranty
3.1 Exclusions from the guarantee
3.2 Delivery and installation
3.3 Warranty: duration
3.4 Warranty: commencement
3.5 Warranty: activation
3.6 Warranty procedure
3.7 Intervention campaigns for faulty products
3.8 Warranty: intervention request
3.9 Non-activation, failure to grant, termination
3.10 Final terms
4 Safety regulations
4.1 General warnings
4.2 Safety indications
4.3 Personal protective equipment
4.4 Preparing for accidents
4.5 Preventing fires and accidents
4.6 Storing dangerous liquids
4.7 Warnings for safe working
4.8 Moving safely
4.9 Road travel
4.10 Momentary stop
4.11 Parking the vehicle
4.12 Starting and stopping the vehicle
4.13 Truck mixers safe working procedures
5 Vehicle description
5.1 Left side components description
5.2 Right side components description
5.3 Engine components description
5.4 Cab components description
6 Safety devices
6.1 List of safety devices
6.2 Safety stickers
7 Components description
7.1 ROPS - FOPS Cab
7.2 Instrument panel
7.3 Parking brake
7.4 Transmission
7.5 Electronic hand throttle
7.6 Drum side rotation control lever
7.7 Loading shovel control lever
7.8 Drum lifting control lever
7.9 Mixing/Unloading Button *
7.10 Mixing/unloading control lever *
7.11 Drum rotation speed control lever *
7.12 Concrete batch control *
7.13 Unloading chute pump
7.14 Chute extension *
7.15 Drum opening pump *
7.16 Cement bag cutter *
7.17 Hydraulic weighing system *
7.18 Water pump
7.19 Wheel wedge
7.20 Water heater *
7.21 FPT Series NEF4, Stage IIIA /Tier 3
8 Equipment
9 Emergency procedure
9.1 Emergency procedures list
9.2 Vehicle towing
9.3 Drum unloading in case of emergency
10 Maintenance
10.1 Maintenance warnings
10.2 Preliminary maintenance operations
10.3 Engine hood opening
10.4 Battery
10.5 Fuel
10.6 Safety stickers: Inspection
10.7 Lubrication
10.8 Engine maintenance
10.9 Air filter: Cleaning and replacement
10.10 Radiator maintenance
10.11 Hydraulic system maintenance
10.12 2 speed transmission maintenance
10.13 Brakes maintenance
10.14 Wheel maintenance
10.15 Drum maintenance
10.16 Lighting
10.17 Window washer fluid tank
10.18 Differential Axles Maintenance
10.19 Hydraulic fittings tightening torques
10.20 Torque specifications - fasteners
11 Technical assistance service
11.1 Spare parts supply
11.2 Assistance to owner / operator
11.3 Technical Assistance Service address
12 Problems diagnostics
12.1 Engine
12.2 Hydraulic transmission system
12.3 Brakes
12.4 Steering wheel
12.5 Drum
12.6 Loading shovel
13 Cleaning
13.1 Machine cleaning
13.2 Glasses cleaning
13.3 Cleaning the cab
13.4 Safety stickers cleaning
13.5 Drum cleaning
14 Lifting the vehicle
15 Transporting the vehicle on a trailer
16 Storing the vehicle
16.1 Long period of inactivity
16.2 Long period of inactivity
16.3 Restarting the vehicle
17 Waste disposal
17.1 Ecological considerations
17.2 Protect the environment
18 Demolition
19 Technical data
19.1 Truck mixer AB L3500
19.2 Truck mixer AB L4700
19.3 Truck mixer AB F7000
19.4 Environmental conditions
19.5 Electromagnetic Interference
19.6 Radiations
19.7 DIECI Hydro Telehandler Fluid ISO46
19.8 DIECI Hydro Telehandler Fluid ISO32
19.9 Declaration of conformity for F-Gas
20 Control and maintenance logs
20.1 Type of logs
20.2 Instructions for compiling the logs
20.3 Control log
20.4 Maintenance log
Notes
