Hitachi ZC35C-5 ZC35T-5 ZC50C-5 ZC50T-5 Vibratory Roller Workshop Manual WTCJ-EN-00

Hitachi ZC35C-5 ZC35T-5 ZC50C-5 ZC50T-5 Vibratory Roller Workshop Manual WTCJ-EN-00
Size: 7.96 MB
Machine: Vibratory Roller
Machine Model: ZC35C-5 ZC35T-5 ZC50C-5 ZC50T-5
Publication Date: 2018
Page: 443 Pages
Parts Number: WTCJ-EN-00

The Bookmarks of Hitachi ZC35C-5 ZC35T-5 ZC50C-5 ZC50T-5 Vibratory Roller Workshop Manual:
Introduction
Symbol And Abbreviation
Safety
Section And Group Contents
Section 1 General
 Group 1 Precautions For Disassembling And Assembling
 Group 2 Tightening
 Group 3 Painting
 Group 4 Bleeding Ai
 Group 5 Preparation
Section 2 Maintenance Standard
 Group 1 Body
Section 3 Body
 Group 1 Pump Device
 Group 2 Travel Device (Front) (Zc35c-5, Zo5t-5)
 Group 3 Travel Device (Front) (Zc5oc-5, Zc5ot-5)
 Group 4 Travel Device (Rear) (Zc35c-5)
 Group 5 Travel Device (Rear) (Zc5oc-5)
 Group 6 Travel Device (Rear) (Zo5t-5)
 Group 7 Travel Device (Rear) (Zc5ot-5)
 Group 8 Vibration, Steering/Charge Pump
 Group 9 Steering Valve
 Group 10 Steering Cylinder
 Group 11 Vibration Motor
 Group 12 Solenoid Valve
 Group 13 Drum
 Group 14 Rear Tie
 Group 15 Center Hinge
 Group 16 Engine
 Group 17 Radiator Assembly
 Group 18 Hydraulic Od Tank
 Group 19 Fuel Tank
 Group 20 Water Spray Pump
 Group 21 Liquid Agent Pump
Service Manual Revision Request Form
