John Deere Hagie STS10 STS12 Self-Propelled Sprayer Repair Technical Manual TM149219

John Deere Hagie STS10 STS12 Self-Propelled Sprayer Repair Technical Manual TM149219
Language: English
Format: PDF
Document: Repair Technical Manual
Machine: Self-Propelled Sprayer
Machine Model: STS10 (S.N. 10S019001—), STS12 (S.N. 12S019001—)
Pages: 626 Pages
Part Number: TM149219

Contents:
  Foreword
  General Information
     Safety
     Specifications
     Tune - Up and Adjustment
     Fuel and Lubricants
  Engine
     Engine
     Cooling System
     Exhaust System
  Fuel and Air
     Diesel Fuel System
     Air Intake System
  Electrical System
     Battery
     Harness and Connector Repair
     Charging Circuit
     Starting Circuit
     Fuses and Relays
     Lighting
     Chassis Control System
     Engine Control System
     Spray Rate Control System
     Boom Control System
     Cab Components
  Power Train
     Hydrostatic Drive Pump
     Hydrostatic Drive Motor
     Final Drive
  Steering and Brakes
     Steering
     Brakes
  Suspension and Tread Adjust
     Suspension
     Tread Adjust Valves
     Tread Adjust Cylinders
     Wheels
  Hydraulic System
     Hydraulic Reservoir
     Hydraulic Pumps
     Hydraulic Valves
     Hydraulic Cylinders
     Hydraulic Motors
     Hydraulic Oil Coolers
  Solution Spray System
     Component Removal and Installation
     Solution Tank
     Solution Pump
     Spray Nozzles
     Control Valves
     Flowmeter
     Rinse Tank
     Eductor
     Direct Injection
     Side Fill
  Pneumatic System
     On Board Air Compressor and Reservoir
     On Board Air Dryer
     Foam Marker
  Operator`s Station
     Cab
     Controls
     Air Conditioning System
     Heating System
     Air Suspension Seat
     Cab Door and Windshield
  Platform
     Platform
  Boom
     Boom - 36 m (120 ft)
     Boom - 27 m and 30 m (90 ft and 100 ft)
  Dealer Fabricated Tools
     Dealer Fabricated Tools
