Komatsu 830E-5 A50154-A50173 Field Assembly Manual CEAW012201 01

Komatsu 830E-5 A50154-A50173 Field Assembly Manual CEAW012201 01

Size: 17.64 MB
Language: English
Machine: Dump Truck
Machine Model: 830E-5
Serial Number: A50154-A50173
Part Number: CEAW012201 01
Publication Date: 2024
Pages: 394 Pages

The Bookmarks of Komatsu 830E-5 A50154-A50173 Field Assembly Manual CEAW012201 01:
FIELD ASSEMBLY MANUAL 830E-5  DUMP
FOREWORD
TABLE OF CONTENTS
SAFETY RULES, TOOLS & EQUIPMENT
TRUCK COMPONENTS AND SPECIFICATIONS
 Truck and Engine
 AC Induction Traction Motorized Wheels
 Suspension
 Operator's Cab
 Power Steering
 Dynamic Retarding Grid
 Brake System
 Selective Catalytic Reduction (SCR)
 Diesel Exhaust Fluid (DEF)
SPECIFICATIONS
MAJOR COMPONENT WEIGHTS
RECEIVING & ASSEMBLY PREPARATION
 Preparation
 Coded Boxes
CHASSIS ASSEMBLY
DUMP BODY ASSEMBLY
 GENERAL INFORMATION
 BODY ASSEMBLY
 BODY WELDING
FINAL ASSEMBLY
 Mount Tires, Rim Adapter, and Torque
 Rear Wheel Installation
 Body
 Body Pad Shimming Procedure
 Rock Ejectors
 Mud Flaps
 Guide Brackets
 Retention Sling
 Body Up Switch Adjustment
 Hoist limit switch adjustment
 Bolt in Lubrication System
 Isolation Box Installation
 Camera and Radar
FINAL CHECKOUT
APPENDIX
 STANDARD TORQUE CHARTS AND CONVERSION TABLES
 SUSPENSION OILING AND CHARGING PROCEDURE
 SUSPENSION OILING AND CHARGING BLOCK KIT INSTALLATION PROCEDURE
 OIL AND NITROGEN SPECIFICATIONS CHART
 FAN CLUTCH CHECKOUT PROCEDURE
 ENGINE EMISSIONS AFTER-TREATMENT SYSTEMS
 TOE-IN ADJUSTMENT
 SEAT BELTS AND TETHERS CHECKOUT PROCEDURE
 ELECTRIC CHECKOUT PROCEDURE
 INTERFACE MODULE CHECKOUT PROCEDURE
 ADDITIONAL ELECTRICAL CHECKOUT FOR TRUCKS WITH IM CONTROLS
 HYDRAULIC CHECKOUT PROCEDURE
 Brake Test Pre-Shift Checkout Procedure
 BRAKE SYSTEM CHECKOUT PROCEDURE
 AUTOMATIC LUBRICATION SYSTEM
 AUTOMATIC LUBRICATION SYSTEM CHECKOUT PROCEDURE
 AIR CONDITIONING SYSTEM CHECKOUT PROCEDURE
 TIRE MONITORING SYSTEM CHECKOUT PROCEDURE
 PAYLOAD METER IV CHECKOUT PROCEDURE
 ALTERNATOR LOCK CHECKOUT PROCEDURE
 KOMTRAX PLUS 2 SHOP SETUP CHECKOUT PROCEDURE
 KOMTRAX PLUS 2 SITE SETUP CHECKOUT PROCEDURE
 KOMVISION® CHECKOUT PROCEDURE
 KOMATSU WIRELESS BRIDGE CHECKOUT PROCEDURE
 RETRACTABLE LADDER SYSTEM CHECKOUT PROCEDURE
 FIELD ASSEMBLY INSPECTION REPORT
 50 HOUR POST-COMMISSIONING CHECKSHEET
