Komatsu HD785-8E0 Field Assembly Manual GEN00209-04

Komatsu HD785-8E0 Field Assembly Manual GEN00209-04

Size: 103.95 MB
Machine: Articulated Dump Truck
Machine Model: HD785-8E0
Serial Number: 55001 and up
Publication Date: 05 2022
Page: 351 Pages
Part Number: GEN00209-04

The Bookmarks of Komatsu HD785-8E0 Articulated Dump Truck Field Assembly Manual:
Cover
1. Foreword
2-1. Precautions For Field Assembly
2-2. Disposal Of Removed Parts
3-1. Schedule
3-2. Layout Of Kit (Work Space Layout)
3-3. Parts Overview (Only For Main Components)
3-4. Dimensions Of Main Components
3-5. Specifications
4-1-1. Tool List For Field Assembly
4-2. Standard Tightening Torque Table
4-3. Coating Materials List
4-4. Selection Of Wire Ropes Used For Assembly
4-5. Selection Of Nylon Slings Used For Assembly
4-6. Relationship Between Work Number Of Assembly Procedureand Packing Tag
5. Field Assembly Procedure
6. Machine Check Sheet For Field Assembly
