Manitou Axle 212 Repair Manual 547983EN

Manitou Axle 212 Repair Manual 547983EN
Size: 42.6 MB
Machine: Axle
Machine Model: Manitou 212 Axle
Publication Date: 2022
Page: 248 Pages
Part Number: 547983EN

Content:
Introduction
Specifications
Maintenance
Safety precautions
Trunnion
Checking wear and replacing the braking discs
Steering knuckle adjustment
(Heavy duty) Steering knuckle adjustment
Double u-joint
Planetary reduction gear
(Heavy duty) Planetary reduction gear
Steering cylinder
(Heavy duty) Steering cylinder
Differential unit
Revel pinion
Manual emergency release
Mechanical parking brake
External hydraulic negaUve brake
External hydraulic negatkfe brake with quick
release
In coming drum brake
4” incoming brake (2 and 3 function versions)
Normal differential unit
Limited slip differential unit (25% and 45%)
Hydraulic differential Pock 100% by selector
fork! piston
Hydraulic negative brake
Incorporated reduction gear and pinion 602
and 603
Counter revolution sensor (drop-in type)
